(1) Assignment of Load Line
The Society is authorized to assign Load Lines to vessels registered by the Korean
Government and other Governments.
(2) Load Line Mark for Ocean Going Vessels without Timber Load Line
The centre of the ring is to be placed on each side of the ship at the middle of the length as
defined in the International Convention on Load Lines, 1966. The ring, lines and letters are to be painted in white or yellow on a dark ground or in black on a light ground. They are also to be permanently marked on the sides of the ship as shown in Fig 1.
(3) Load Line Mark for Ocean Going Vessels with Timber Load Line
The centre of the ring is to be placed on each side of the ship at the middle of the length as defined in the International Convention on Load Lines, 1966. The ring, lines and letters are to
be painted in white or yellow on a dark ground or in black on a light
to be permanently marked on the sides of the ship as shown in Fig 2.
ground. They are also
LOAD LINE MARKS
