(3) Test items, test method and criteria

The requirements in Table 3.17.2 are, in principle, to be considered as the criteria for the type

tests of flexible hose assembly of metallic materials. A test method other than those given in the following table may be employed by this Society if deemed appropriate of its equivalency.


Table 3.17.2 Testing methods and Criteria of flexible hose assembly of metallic materials


Test Item

Test Method

Criteria

Measurement of Dimension


Diameter

Measure dimensions using vernier calipers, plug gauge, taper gauge or inside calipers etc.

The diameter is to be with- in allowable tolerance.

Performance Test


Impulse Test

Test pressure :

A pressure 1.5 times of the design pressure.

Test medium : water.

Test cycle : 0.5 Hz ~ 1.7 Hz, 150,000 times.

This test is to be applied on the piping systems where pressure

pulses are expected to occur in service.


During test period, no rup- turing, leaking are permitted.


Bending Fatigue Test

(1) U bend test

Bend radius : see ISO 10380 Table 2.

Test pressure : design pressure.

Test medium : water.

Test cycle :

5 cycles/min. to 30 cycles/min. for 5 min.





A localized reduction of the hose radius is not to be more than 50 % during the test.

During test period, no rup- turing, leaking are permitted.


Guidance for Approval of Manufacturing Process and Type Approval, Etc. 2015 113



Table 3.17.2 Testing methods and Criteria of flexible hose assembly of metallic materials


Test Item

Test Method

Criteria


Bending Fatigue Test

(2) Cantilever bend test

Stroke : see ISO 10380 Table 4.

Test pressure : design pressure.

Test medium : water.

Test cycle :

3 cycles/min. to 15 cycles/min. for 5 min.





A localized reduction of the hose radius is not to be more than 50 % dur- ing the test.

During test period, no rupturing, leaking are permitted.


Bend Test

Bend radius : see ISO 10380 Table 2.

Test pressure : without pressure in hose.

Test medium : water.

Test cycle : 5 cycles/min. to 25 cycles/min. for 5 min.




Following the bend test, a pressure test is to be carried out at a pressure 1.5 times of the design pressure for 2 minutes.


During test period, no rupturing, leaking are permitted.

Burst Test

Test pressure : a pressure 4 times of the design pressure.

Test duration : 5 minutes.


1704. Markings

Type approved flexible metal hose assemblies are to be permanently marked by the manufacturer with the following details

(1) Hose manufacturer’s name or trademark.

(2) Date of manufacture (month/year).

(3) Designation type reference.

(4) Nominal diameter, Pressure rating, Temperature rating.


114 Guidance for Approval of Manufacturing Process and Type Approval, Etc. 2015



1705. Product Inspection after type approval

Flexible hose assembly of metallic or non-metallic materials used for Class I and II pipe fittings is subjected to a hydrostatic test at a pressure 1.5 times of the design pressure.
